额定容量

Capacity

50,100,200,300,500,1000kg

输出灵敏度

Rated output

2.0±10%mV/V

零点输出

Zero balance

≤1%F.S.

非线性

Non-linearity

≤0.017%F.S.

滞后

Hysteresis

≤0.017% F.S.

重复性

Repeatability

≤0.01% F.S.

蠕变（30min）

Creep(30min)

≤0.017% F.S.

温度灵敏度漂移

Temp.effect on output

≤0.002% F.S./10℃

零点温度漂移

Temp.effect on zero

≤0.002% F.S./10℃

输入电阻

Input impedance

380±20Ω

输出电阻

Output impedance

350±10Ω

绝缘电阻

Insulation

≥5000MΩ/100VDC

激励电压

Recommended excitation

5V

最大激励电压

Maximum excitation

15V

温度补偿范围

Compensated temp range

-10~40℃

工作温度范围

Operation temp range

-40~65℃

安全超载

Safe overload

150%F.S.

极限超载

Ultimate overload

200%F.S.

电缆线尺寸

Cable size

Φ6×3000mm

材料

Material

Stainless steel  (不锈钢)

防护等级

IP Class

IP68

最大台面尺寸

Maximum mesa size

500×500mm,600×800mm,800×1000mm

拧紧力矩

Tightening torque

30N.m  160N.m
